Teravision Terasmart 4 Wire AHD Intercom Smart Monitor
The indoor monitor consists of a 7" TFT LCD Display along with built-in Wi-Fi module. The monitor not only works standalone, but also has the ability to connect with 6 more indoor monitors, 2 outdoor stations, 2 CCTV Cameras and 2 Alarm sensors. The monitor has a multi-language functionality in the menu. The monitor also supports motion detection via SD Card.
7 inch LCD colour screen with touch sensor’s button.
Internal memory to store the snapshot ( 86 pictures, automatic cycle) ,and store the snapshots and videos store in 32GB SD Card.
Support” Leave Message” and ” Motion Detection ” SD Card required.
Specifications
| Monitor | 7" TFT LCD Video |
| Product Type | AHD (720P&960P)/CVBS Video Input |
| Resolution | 1024(H)*3(RGB)*600(V) |
| Memory | Support Max. 32GB SD card |
| Intercom Mode | Hands-free dual-way communication |
| Conversation duration | 120s |
| Wi-Fi frequency | 2.4Ghz |
| Network interface | 10M/100M self-adaption |
| IEEE standard | IEEE 802. 11b/g/n |
| Operation way | Touch button |
| Power Consumption | 400mA Max. |
| Power Supply | External power DC12V |
| Support | 2 Outdoor Station + 6 Indoor Monitor + 2 CCTV Camera & 2 Alarm |
| Material | Acrylic wire drawing shell |
| Operation Temperature | -10℃ +60℃ |
| Installation | Surface mount |
| Standard | PAL/NTSC |
| Compliance | CE, C-Tick, FCC, ROHS |
Teravision Outdoor Intercom Call Station with RFID & Keypad
The outdoor station provides communication between the visitor and the people inside the house. Clear identification of people in highly variable conditions. It has 1/2.7" colour CMOS camera which provides sharp resolution of 960P in colour with 2.2 mm lens for the camera.
RFID & Passcode unlock feature allows people to get access with the help of the RFID card details stored on the outdoor station
** The outdoor station must be connected to Teravision 4-wire monitor with Wi-Fi for Terasmart mobile app connectivity.
Specifications
| Camera Sensor | 1/2.7" CMOS, 1.3MP / 2.2 mm lens |
| View Angle | wide angle lens - 140° |
| Night vision | IR LED |
| Power Consumption | 200mA Max. |
| Power Supply | External DC 12V 1A |
| Material | Aluminium Alloy Panel |
| Waterproof | IP65 |
| Operation Temperature | -40℃ +50℃ |
| Unique Feature | RFID & Passcode Unlock |
| Installation | Surface Mount |
| Compliance | CE, C-Tick, FCC, ROHS |
Teravision Outdoor Intercom Call Station
The outdoor station, with the plug-and-play function, doesn't need a separate power supply as the indoor monitor supplies power to the call station with a simple 4-wire connection. The outdoor station has 1/3" colour CMOS camera that provides sharp resolution of 960P in colour with 1.9mm lens camera. The monitor has a built-in motion detection feature to detect any person passing through.
- Built-in motion detection sensor and IR or LED clear night vision
- Leave Message Function Optional
- Aluminium alloy material with IP65 Waterproof
** The outdoor station must be connected to Teravision 4-wire monitor with Wi-Fi for Terasmart mobile app connectivity.
Specifications
| Camera Sensor | 1/3" CMOS, 1.3MP / 1.9 mm lens |
| View Angle | wide angle lens - 140° |
| Night vision | IR LEDs |
| Power Consumption | 200mA Max. |
| Material | Aluminium Alloy Panel |
| Waterproof | IP65 |
| Operation Temperature | -40℃ +50℃ |
| Unique Feature | With Rain cover |
| Installation | Surface mount |
| Compliance | CE, C-Tick, FCC, ROHS |
